1. SONOFF Zigbee Devices
2. Third-Party Zigbee 3.0 Devices
Zigbee Bridge Ultra currently supports Zigbee 3.0 devices from other brands. See the supported categories below.
| Device Type | Category |
| Plug | Single-channel Plug; Multi-channel Plug |
| Switch | Single-channel Switch; Multi-channel Switch |
| Sensor | Motion Sensor |
| Vibration Sensor | |
| Contact Sensor | |
| Temperature Sensor; Temperature and Humidity Sensor |
|
| Illumination Sensor | |
| Gas Sensor | |
| Smoke Sensor | |
| Water Leak Detector | |
| Light | Dimmable Light |
| Tunable white Light | |
| Tunable color Light | |
| Dimmer | Dimmer |
| Curtain | Curtain |
| Thermostat | Thermostat |
| Button | Button |
| Water Valve | Smart Water Valve |
*The supported device types are infered based on Matter Standard. If you encounter any issues connecting your devices, please contact our technical support at: support@sonoff.tech
3. Matter-enabled Wi-Fi Devices
| Brand/Vendor | Model | Capabilities in Matter Platform |
| SONOFF | BASICR2 | On/Off Control |
| BASICR4 | On/Off Control | |
| RFR2 | On/Off Control | |
| MINIR2 | On/Off Control | |
| MINIR4 | On/Off Control | |
| MINIR4M | On/Off Control | |
| S26R2 | On/Off Control | |
| S31 | On/Off Control | |
| S31 Lite | On/Off Control | |
| S40TPB | On/Off Control | |
| S40TPA | On/Off Control | |
| S40TPB Lite | On/Off Control | |
| S40TPA Lite | On/Off Control | |
| 4CHR3 | On/Off Control | |
| 4CHPROR3 | On/Off Control | |
| POWR3 | On/Off Control | |
| Micro | On/Off Control | |
| TX1C/2C/3C | On/Off Control | |
| DUALR3 | Switch Mode: On/Off Control; Motor Mode: 1. Open/Close 2. On/Off Status Reporting 3. Motor Position Change Reporting 4. Percentage Control ; *Percentage control is inaccurate when the motor is not calibrated. *During the device's offline period, status changes will not automatically sync with Apple Home after returning online. Please restart the matter hub. |
|
| THR316/316D | On/Off Control | |
| THR320/320D | On/Off Control | |
| SV | On/Off Control | |
| T5 Series | On/Off Control | |
| M5 Series | On/Off Control | |
| DUALR3 Lite | On/Off Control | |
| SPM-4Relay | On/Off Control | |
| POWR316/POWR316D | On/Off Control | |
| POWCT | On/Off Control | |
| S60TPF/TPG | On/Off Control | |
| NSPanel | On/Off Control | |
| D1 | 1. On/Off Control 2. Brightness Adjustment |
|
| B02-F-A19/B02-F-A60 | 1. On/Off Control 2. Brightness Adjustment 3. Color Temperature Adjustment |
|
| B05-B-A60 | 1. On/Off Control 2. Brightness Adjustment 3. Color Temperature Adjustment 4. Color Adjustment |
|
| B05-BL-A60/B05-BL-A19 | 1. On/Off Control 2. Brightness Adjustment 3. Color Temperature Adjustment |
|
| iFan04 | On/Off Control |
4. Home Assistant Entities
| HA Entity | Matter Device Type | Capabilities Sync to Matter |
|---|---|---|
| Switch (with state on/off) | On/Off Plug-in Unit | Outlet on / off |
| Binary sensor (with deviceClass moving / motion / occupancy / smoke / CO / Gas /) | Occupancy Sensor | XX.Detected / Not Detected |
| Binary sensor (with deviceClass smoke ) | Smoke CO Alarm | XX.Detected / Not Detected |
| Binary sensor (with deviceClass door / garage_door / window ) | Contact Sensor | Occupied / Not Occupied |
| sensor (with deviceClass humidity) | Humidity Sensor | Humidity |
| sensor (with deviceClass temperature) | Temperature Sensor | Temperature |
| sensor (with deviceClass / Smoke / CO / Gas ) | Smoke CO Alarm | Smoke-numeric-unit |
| sensor (with deviceClass CO2 / AQI / PM2.5 / TVOC ) | Air Quality Sensor | XX-numeric-unit |
| Light (with state on / off and attributes brightness) | Dimmable Light | Light on/off, Brightness |
| Light (with state on / off and attributes brightness / color_temp) | Color Temperature Light | Light on / off, Brightness, Color temperature |
| Light (with state on/off and attributes brightness / color temp/hs_color / rgb_color | Color Temperature Light | Light on / off, Brightness, Color temperature, Hs_color / xy_color / rgb_color |
| Light (with state on/off and attributes brightness / xy_color) | Extended Color Light | Light on / off, Brightness, Color temperature, xy_color |
| Event (Single / Double / Long press) | Generic Switch | Single Press, Double Press, Long Press |
| Event (Single / Double / Long press) | Generic Switch | Single Press, Double Press, Long Press |
| Cover (with state open/closed/ opening/closing and attribute current_position) | Window Covering | Motor control, Specific position |
| Climate (with state hvac_mode (OFF / HEAT) and current temperature/target temperature) | Thermostat | Current temperature, Thermostat mode, Target temperature |
| Climate (with state hvac_mode (OFF / HEAT) and current temperature/target temperature/fan_modes/ swing_modes) | Thermostat & Fan | Air Conditioner on / off, Target Temperature, Temperature, HVAC Modes, Fan Modes, Oscillate |
| Fan (with state on/off and Speed /Oscillate ) | Fan | Fan on / off, Wind Speed, Oscillate |
