Call Intercom, More Convenient Communication
With built-in microphone and speaker, it supports using mobile phone to call panel and panel-to-panel calls.
SONOFF NSPanel Pro Smart Home Control Panel 86 Type
Tax included. Shipping calculated at checkout
【All-in-One Control】NSPanel Pro supports unlimited SONOFF devices—from smart lights and cameras to sensors and switches. Future SONOFF devices will also be compatible, ensuring long-term scalability.
【Built-in Zigbee Hub】Easily batch-add Zigbee devices via the touchscreen. The standard Zigbee 3.0 protocol ensures stable connections and wider coverage. The added sub-devices can be voice-controlled via Alexa, Google Home, and more.
【Smart Security】Create up to 3 custom security modes with different arming configurations. Once armed, the triggered sensor will activate an alarm on the panel and send instant alerts to your phone.
【Temperature Control】Select the temperature source (e.g., TH Elite) and control devices (e.g., MINIR4M, ZBMINIL2) to build a personalized thermostat system that keeps your space comfortable.
【Live Camera Monitoring】NSPanel Pro functions as a real-time display for the supported cameras. Monitor key areas like the living room, garage, or bedroom directly from the panel at any time.
Technical details, troubleshooting or setup tips? Access the NSPanel Pro knowledge center for all the info you need.
SONOFF NSPanel Pro Smart Home Control Panel 86 Type
Sale price€81,95
Regular price€122,95
NSPanel Pro Smart Home Control Panel
Live Your Smart Life What It Shoud Be
Centrally control all your devices and scenes, integrate Zigbee gateway with home security, compatible with more brands, and with more practical functions such as power consumption statistics, thermostat, call intercom, etc.
Smart Home is All within Grasp
All-in-one Control
Unlimited number of control devices, supports control all SONOFF devices, from smart lights, smart cameras,
security sensors to switches, etc., and will continue to support SONOFF new device in the future.
Local Control via LAN
NSPanel Pro local controls SONOFF devices via LAN, offering faster response times and greater reliability.
Even with poor network conditions, it can still maintain stable control.
*Controlled SONOFF devices need to have and enable LAN control.
Matter Closer to Everyday Life
NSPanel Pro supports working as a Matter hub (Matter controller), allowing third-party
Matter devices to be added via NSPanel Pro and controlled directly on the screen.
Reliable and Stable Zigbee Gateway
Quickly add Zigbee devices on the screen in batches. Standard Zigbee 3.0 protocol makes the connection more stable and the
coverage wider. Added sub-devices can be voice controlled by working with Alexa, Google Home, and more.
Support All SONOFF Zigbee Devices
Support Third-party Standard Zigbee 3.0 Device
Customize Your Home Security Mode
Customize 3 modes by setting different arming devices. After arming, once the sensor is triggered, the panel will alarm,
and you will receive a notification alert on the phone.
Smart Temperature Control, Make Life Easier
Choose the temperature source and execution devices to form your own thermostat. Keep a suitable room temperature for you.
Manual Mode
Adjust temperature at any time.
Autol Mode
Control the execution device on/off automatically according to the temperature threshold to realize automation.
Calls are Communicated Promptly
View and Talk by Camera
Used with a smart camera, when someone comes to visit, check the situation through the camera first toconfirm safety. It also
supports two-way talk to make communication easier
Customization Makes it Convenient
You can freely customize the home screen style or wallpaper of the NSPanel Pro, creating an attractive interface that makes your daily use more convenient.
Explore Richer Functions
in Webpages
Listening to music, watching videos, or
checking out the latest advice? Save the
address in NSPanel Pro's Webpages, start it
quickly with one click, and relax at any time.
Multi Capabilities Assembled Here
eWeLink-Remote Control
After adding R5 or S-MATE2, effortlessly control various devices from different locations within your home by creating different scenes.
Power Consumption
Work with energy-monitoring smart devices to track daily usage.
More Expansion
Wiring
Quick Start
Download the eWeLink App.
Powering on, tap "Start" to select the Wi-Fi and enter the password. Enter the main interface by following the prompts.
Tap "Log in" on the device and tap "+" on the eWeLink App to select "Scan".
Begin to use.
Packages
Accessories
Specs & User Manual
SONOFF NSPanel Pro is an all-in-one smart home control panel with a built-in Zigbee 3.0 hub, allowing you to manage lights, switches, sensors, cameras, and more from a single touchscreen interface. It supports voice control via Alexa and Google Home, real-time security alerts with custom arming modes, and integration with supported cameras for live monitoring. NSPanel Pro also enables smart temperature control by setting temperature sources and controlling devices, offering a seamless personalized thermostat solution for modern smart homes.
User Manual (PDF)Zigbee
IEEE 802.15.4 (Zigbee 3.0)
Wi-Fi
IEEE 802.11 b/g/n 2.4GHz
Input
100-240V AC 50/60Hz
Max Power Consumption
5W MAX; 150mA
TFT Screen Size
3.95" (Capacitive Screen)
Screen Resolution
480 x 480
MCU
PX30
CPU
4-cores Cortex-A35
GPU
Mali-G31GPU
RAM
2GB, DDR3
ROM
8GB, eMMC 5.1
Certifications
CE/UKCA/ SRRC/RoHS
Shell Materials
PC V0+CRS+Toughened Glass
Dimension
86x86x39.5mm
FAQ
1. Which Zigbee sub-devices can be added to NSPanel Pro？
It supports all SONOFF Zigbee devices and other brands' devices with standard protocols. Philips Hue lights and IKEA lights will be supported in 1.2.1.
2. Does NSPanel Pro have relays?
It doesn’t have the relay. NSPanel Pro is a smart home control panel.
3. How does it work with Home Assistant?
You can access the HA page in the LAN through the Web Shortcut function of NSPanel Pro.
4. What kinds of cameras does NSPanel Pro support？
NSPanel pro supports adding four types of cameras: SONOFF Camera, RTSP Camera, ESP32 Camera and eWeLink Camera app.
5. Is the NSPanel Pro Android system or source code open-sourced?
The Android OS source code of NSPanel Pro comes from Rockchip, which is restricted by NDA and commercial license terms, thus, it is not public or open-sourced. However, we will release the device API docs for third-party home automation platform integration, we are considering publishing the schematic diagram and Linux Kernel source code of NSPanel Pro for your secondary development if you are able to get related development documentation or source code of the Rockchip PX30 chip from Rockchip support or others.
Here is the Linux Kernel code and related schematic：
Linux Kernel：https://github.com/itead/NSPro_Kernel
Zigbee IO Definition：https://cdn.shopify.com/s/files/1/0742/9963/8001/files/NSPanel-Pro-Zigbee-IO.pdf?v=1749448998
EFR32 Guide: https://cdn.shopify.com/s/files/1/0742/9963/8001/files/ug129-zigbee-gateway-ref-design-guide.pdf?v=1749448778
