NSPanel Pro Supported Devices List

1.NSPanel Pro Supported SONOFF Devices


Protocol	Series	Product Description	Model
Wi-Fi	DIY Smart Switch	1-gang switch	MINIR2, MINIR3, MINIR4, MINIR4M, MINI-D, MINIRBS, BASIC, BASICR2, BASICR3, BASICR4, RFR2, Basic-1GS
		2-gang switch	DUALR2
		4-gang switch	4CHR3, 4CHPROR3
		Roller Shutter	MINI-RBS
		1-gang temperature and humidity monitoring swtich	TH10, TH16, TH Origin, TH Elite, THR316/THR320,THR316D/THR320D,
		1-gang power metering swtich	POWR2, POWR3, POW Origin, POW Elite, POWCT
		1-gang dimmer switch	D1
		1-gang USB adapter	Micro, Micro-CFH
		1-gang E27 lamp holder	SlampherR2
		Ceiling Fan And Light Controller	iFan04
		2-gang switch with motor mode	DUALR3, DULAR3 Lite
		4-gang smart stackable power meter	SPM-4Relay
	Smart Wall Switch	1/2/3-gang wall switch (touch)	TX Series(T0, T1, T2, T3， T6), TX Ultimate
		1/2/3-gang wall switch (push button)	SwtichMan M5 Series
		1-gang wall power metering switch	IW101
		1-gang wall power metering plug(typeB)	IW100
	Smart Lighting	warm & cold LED bulb	B02-B-A60, B02-BL-A60, B02-BL-A19
		RGB LED bulb	B05-B-A60, B05-BL-A60, B05-BL-A19
		warm & cold filament bulb	B02-F-A19, B02-F-A60, B02-F-ST64
		RGB smart LED strip lights	L1, L1 Lite, L2, L2 Lite, L3, L3-P
	Home Security	Smart Home Security Camera	CAM-Slim, GK-200MP2-B, CAM-PT2, CAM-B1P
	Home Security	Wi-Fi Wireless Door Window Sensor	DW2-Wi-Fi
	Central Control Panel	2-gang control panel	NSPanel
	Smart Plug	1-gang plug	S26, S26R2, S31 Lite, S40 Lite
	Smart Plug	1-gang power metering plug	S31, S40, S60
Zigbee	DIY Smart Switch	1-gang switch	ZBMINI, ZBMINIR2, BASICZBR3, ZBMicro
		1-gang switch(no neutral wire required)	ZBMINI-L, ZBMINL2
		2-gang switch	MINI-ZB2GS
		2-gang switch(no neutral wire required)	MINI-ZB2GS-L
		Roller Shutter	MINI-ZBRBS
	Smart Wall Switch	1/2/3-gang wall switch (push button)	SwtichMan ZBM5 Series
	Home Security	Zigbee sensor	SNZB-01/01P/01M, SNZB-02/02P/02D/02LD/02WD/02DR2, SNZB-03/03P, SNZB-04/04P, SNZB-05P, SNZB-06P
	Home Appliance	Zigbee smart curtain motor	ZBCurtain, TRVZB, SWV
	Smart Plug	1-gang plug	S26R2ZB, S31ZB Lite, S40ZB Lite, S60ZBTPF/TPG
eWeLink-Remote	eWeLink-Remote sub-devices	DIY Smart Switch	S-MATE, S-MATE2
eWeLink-Remote	eWeLink-Remote sub-devices	Scene Controller	R5, R5W

Supports Devices Controlled Via LAN

When NSPanel Pro and the listed devices are in the same LAN, they can be controlled via the LAN on the NSPanel Pro screen.


Protocol	Series	Product Description	Model
Wi-Fi	DIY Smart Switch	1-gang switch	MINIR2, MINIR3, MINIR4, MINIR4M, BASICR2, BASICR3, BASICR4, RFR2,
		2-gang switch	DUALR2
		4-gang switch	4CHR3, 4CHPROR3
		1-gang temperature and humidity monitoring swtich	TH10, TH16, TH Origin, TH Elite
		1-gang power metering swtich	POWR2, POWR3, TH Origin, TH Elite, POWCT
		1-gang dimmer switch	D1
		1-gang USB adapter	Micro, Micro-CFH
		1-gang E27 lamp holder	SlampherR2
		2-gang switch with motor mode	DUALR3, DULAR3 Lite
	Smart Wall Switch	1/2/3-gang wall switch(touch)	TX Series(T0, T1, T2, T3), TX Ultimate
		1/2/3-gang wall switch(push button)	SwtichMan M5 Series
		1-gang wall power metering switch	IW101
		1-gang wall power metering plug(typeB)	IW100
	Smart Lighting	warm & cold LED bulb	B02-BL-A60, B02-BL-A19
	Smart Lighting	RGB LED bulb	B05-BL-A60, B05-BL-A19
	Central Control Panel	2-gang control panel	NSPanel
	Smart Plug	1-gang plug	S26, S26R2, S31 Lite, S40 Lite
	Smart Plug	1-gang power metering plug	S31, S40, S60

2. "Matter Bridge" Feature Supported Devices

The SONOFF Wi-Fi Device

Product Type	Model	Capabilities in Matter Platform
DIY Smart Switch	BASICR2	On/Off Control
	BASICR4	On/Off Control
	RFR2	On/Off Control
	MINIR2	On/Off Control
	MINIR4	On/Off Control
	MINIR4M	On/Off Control
	4CHR3	On/Off Control
	4CHPROR3	On/Off Control
	POWR3	On/Off Control
	Micro	On/Off Control
	THR316/316D	On/Off Control
	THR320/320D	On/Off Control
	DUALR3 Lite	On/Off Control
	POWR316/POWR316D	On/Off Control
	POWCT	On/Off Control
	DUALR3	Switch Mode: On/Off Control; Motor Mode: 1. Open/Close 2. On/Off Status Reporting 3. Motor Position Change Reporting 4. Percentage Control ; Percentage control is inaccurate when the motor is not calibrated. During the device's offline period, status changes will not automatically sync with Apple Home after returning online. Please restart the matter hub.
	iFan04	On/Off Control
Smart Plug	S26R2	On/Off Control
	S31	On/Off Control
	S31 Lite	On/Off Control
	S40TPB	On/Off Control
	S40TPA	On/Off Control
	S40TPB Lite	On/Off Control
	S40TPA Lite	On/Off Control
	S60TPF/TPG	On/Off Control
Smart Wall Switch	TX1C/2C/3C	On/Off Control
	T5 Series	On/Off Control
	M5 Series	On/Off Control
Central Control Panel	NSPanel	On/Off Control
Wire splicing connector	D1	1. On/Off Control 2. Brightness Adjustment
Smart Lighting	B02-F-A19/B02-F-A60	1. On/Off Control 2. Brightness Adjustment 3. Color Temperature Adjustment
	B05-B-A60	1. On/Off Control 2. Brightness Adjustment 3. Color Temperature Adjustment 4. Color Adjustment
	B05-BL-A60/B05-BL-A19	1. On/Off Control 2. Brightness Adjustment 3. Color Temperature Adjustment

The SONOFF Zigbee Device

Product Type	Model	Capabilities in Matter Platform
DIY Smart Switch	ZBMINI	On/Off Control
	BASICZBR3	On/Off Control
	ZBMINI-L	On/Off Control
	ZBMINL2	On/Off Control
	MINI-ZBRBS	On/Off Control
	ZBMicro	On/Off Control
	ZBMINIR2	On/Off Control
Smart Wall Switch	ZBM5 1C/3C	On/Off Control
Sensors	SNZB-01	Click *Recognized as a switch device, uncontrollable in Google Home. Not supported in Alexa.
	SNZB-01P	Click *Recognized as a switch device, uncontrollable in Google Home. Not supported in Alexa.
	SNZB02DR2	Temperature and humidity data *Humidity is not supported in Alexa.
	SNZB-02D	Temperature and humidity data *Humidity is not supported in Alexa.
	SNZB-02WD	Temperature and humidity data *Humidity is not supported in Alexa.
	SNZB-02LD	Temperature data
	SNZB-02P	Temperature and humidity data *Humidity is not supported in Alexa.
	SNZB-02	Temperature and humidity data *Humidity is not supported in Alexa.
	SNZB-03	Motion detected、No motion detected
	SNZB-03P	Motion detected、No motion detected
	SNZB-04	Opened、Closed
	SNZB-04P	Opened、Closed
	SNZB-05P	1. Leak detected、No leak detected 2. Battery level *Not supported in Alexa
	SNZB-06P	Motion detected、No motion detected
Home Appliance	ZBCurtain	1. Open/Close 2. On/Off Status Reporting 3. Motor Position Change Reporting 4. Percentage Control Pause function is supported in Alexa. Percentage control is inaccurate when the motor is not calibrated.
	TRVZB	1. On/Off Control 2. Set Target Temperature 3. Temperature Reporting 4. Set Operating Mode a. Manual Mode b. Energy Saving Mode (Off Mode)
	SWV-BSP	1. Valve Configuration and Control 2. Flow Measurement (Server) * Supported only in Google Home. Alexa, Apple Home and SmartThings don't support water valve as a device type.
Smart Plug	S26R2ZB	On/Off Control
	S31 Lite ZB	On/Off Control
	S40ZB Lite	On/Off Control
	S60ZB Series	On/Off Control

The Third-Party Zigbee 3.0 Device

Category	Device Type	Capabilities in Matter Platform
Plug	Matter On/Off Plug-in Unit	On/Off Control
Switch	Matter On/Off Plug-in Unit	On/Off Control
Sensor	Motion Sensor	Occupancy Sensing
	Electrical Sensor	1.Electrical Power Measurement2.Electrical Energy Measurement *Supported only in SmartThings
	Vibration Sensor	Occupancy Sensing
	Air Quality Sensor	1.Air Quality2.Temperature Measurement3.Relative Humidity Measurement4.PM2.5 Concentration Measurement5.Total Volatile Organic Compounds Concentration Measurement6.Carbon Monoxide Concentration Measurement7.Carbon Dioxide Concentration Measurement
	Contact Sensor	Boolean State
	Temperature Sensor	Temperature Measurement
	Humidity Sensor	Relative Humidity Measurement
	Light/Illumination Sensor	Illuminance Measurement
	Smoke Sensor/ CO Sensor	1.Smoke CO Alarm2.Carbon Monoxide Concentration Measurement
	Water Leak Detector	Boolean State
Light	Dimmable Light	1.On/Off Control2.Level Control
Light	Color Temperature Light;Extended color Light	1.On/Off Control2.Level Control3.Color Control
Color Dimmer Switch	Generic Switch	Switch
Curtain	Window Covering	Window Covering
Thermostat	Thermostat	1.Thermostat2.Thermostat User Interface 3.Configuration4.Energy Preference5.Fan Control6.Temperature Measurement7.Relative Humidity Measurement8.Occupancy Sensing
Button	Generic Switch	Switch

Home Assistant Entities

HA Entity	Matter Device Type	Capabilities Sync to Matter
Switch (with state on/off)	On/Off Plug-in Unit	Outlet on / off
Binary sensor (with deviceClass moving / motion / occupancy / smoke / CO / Gas /)	Occupancy Sensor	XX.Detected / Not Detected
Binary sensor (with deviceClass smoke )	Smoke CO Alarm	XX.Detected / Not Detected
Binary sensor (with deviceClass door / garage_door / window )	Contact Sensor	Occupied / Not Occupied
sensor (with deviceClass humidity)	Humidity Sensor	Humidity
sensor (with deviceClass temperature)	Temperature Sensor	Temperature
sensor (with deviceClass / Smoke / CO / Gas )	Smoke CO Alarm	Smoke-numeric-unit
sensor (with deviceClass CO2 / AQI / PM2.5 / TVOC )	Air Quality Sensor	XX-numeric-unit
Light (with state on / off and attributes brightness)	Dimmable Light	Light on/off, Brightness
Light (with state on / off and attributes brightness / color_temp)	Color Temperature Light	Light on / off, Brightness, Color temperature
Light (with state on/off and attributes brightness / color temp/hs_color / rgb_color	Color Temperature Light	Light on / off, Brightness, Color temperature, Hs_color / xy_color / rgb_color
Light (with state on/off and attributes brightness / xy_color)	Extended Color Light	Light on / off, Brightness, Color temperature, xy_color
Event (Single / Double / Long press)	Generic Switch	Single Press, Double Press, Long Press
Event (Single / Double / Long press)	Generic Switch	Single Press, Double Press, Long Press
Cover (with state open/closed/ opening/closing and attribute current_position)	Window Covering	Motor control, Specific position
Climate (with state hvac_mode (OFF / HEAT) and current temperature/target temperature)	Thermostat	Current temperature, Thermostat mode, Target temperature
Climate (with state hvac_mode (OFF / HEAT) and current temperature/target temperature/fan_modes/ swing_modes)	Thermostat & Fan	Air Conditioner on / off, Target Temperature, Temperature, HVAC Modes, Fan Modes, Oscillate
Fan (with state on/off and Speed /Oscillate )	Fan	Fan on / off, Wind Speed, Oscillate

3."Thermostat" Feature Supported SONOFF Devices

The Temperature Source Device


Protocol	Series	Product Description	Model
Wi-Fi	DIY Smart Switch	1-gang temperature and humidity monitoring swtich	TH10, TH16, THR316, THR316D, THR320, THR320D
Zigbee	Home Security	Zigbee sensor	SNZB-02, SNZB-02D, SNZB-02P, SNZB-02DR2, SNZB-02LD,SNZB-02WD

The Thermostat Device

The Action Device


Protocol	Series	Product Description	Model
Wi-Fi	DIY Smart Switch	1-gang switch	MINIR2, MINIR3, MINIR4, MINIR4M, MINI-D, BASIC, BASICR2, BASICR3, BASICR4, RFR2, Basic-1GS
		2-gang switch	DUALR2
		4-gang switch	4CHR3, 4CHPROR3
		1-gang temperature and humidity monitoring swtich	TH10, TH16, TH Origin, TH Elite
		1-gang power metering swtich	POWR2, POWR3, POW Origin, POW Elite
		1-gang USB adapter	Micro, Micro-CFH
		1-gang E27 lamp holder	SlampherR2
	Smart Wall Switch	1/2/3-gang wall switch(touch)	TX Series(T0, T1, T2, T3)
		1/2/3-gang wall switch(push button)	SwtichMan M5 Series
		1-gang wall power metering switch	IW101
		1-gang wall power metering plug (type B)	IW100
	Smart Plug	1-gang plug	S26, S26R2, S31 Lite, S40 Lite
	Smart Plug	1-gang power metering plug	S31, S40, S60
Zigbee	DIY Smart Switch	1-gang switch	ZBMINI, ZBMINIR2, BASICZBR3
	DIY Smart Switch	1-gang switch(no neutral wire required)	ZBMINI-L, ZBMINIL2
	Smart Plug	1-gang plug	S26R2ZB, S31ZB Lite, S40ZB Lite, S60ZBTPF/TPG

4."Smart Security" Feature Supported SONOFF Devices

The Trrigger Device


Protocol	Series	Product Description	Model
Zigbee	Home Security	Zigbee Wireless Switch	SNZB-01/01P
		Zigbee Motion Sensor	SNZB-03/03P
		Zigbee Wireless Door/Window Sensor	SNZB-04/04P
		Zigbee Human Presence Sensor	SNZB-06P

5. Compatible with Third-party Devices

Supported Third-Party Zigbee 3.0 Device Types


	Device Type in CSA
Switch	On/Off Output
	On/Off Light
	On/Off Light Switch
	Level Control Switch
Plug	Smart Plug
	Dimmable Light
	Color Dimmable Light
	Color Temperature Light
	Extended Color Light
Temperature and Humidity Sensors	Temperature Sensor
IAS Security Sensor	IAS Zone
Curtain	Window Covering Device

Supported Third-Party Matter Device Types


Matter Device Type	Device Name
On/Off Switch	Matter Switch
Extended Color Light	Matter Light
Matter Bridge	Matter Bridge
On/Off Light Switch	Matter Light Switch
Color Temperature Light	Matter CT Light
Temperature Sensor, Humidity Sensor	Matter Temperature Humidity Sensor
Contact Sensor	Matter Contact Sensor (Door&Window Sensor)
Occupancy Sensor	Matter Presence Sensor/Motion Sensor
Generic Switch	Matter Wireless Button

NSPanel Pro Supported Devices List

1.NSPanel Pro Supported SONOFF Devices

Supports Devices Controlled Via LAN

2. "Matter Bridge" Feature Supported Devices

The SONOFF Wi-Fi Device

The SONOFF Zigbee Device

The Third-Party Zigbee 3.0 Device

Home Assistant Entities

3."Thermostat" Feature Supported SONOFF Devices

The Temperature Source Device

The Thermostat Device

The Action Device

4."Smart Security" Feature Supported SONOFF Devices

The Trrigger Device

5. Compatible with Third-party Devices

Supported Third-Party Zigbee 3.0 Device Types

Supported Third-Party Matter Device Types

6. Compatible with Home Assistant

Device Types in HA That Can be Synced to NSPanel Pro

Device Types in NSPanel Pro That Can be Synced to HA

Reading next

NSPanel Pro Supported Devices List

1.NSPanel Pro Supported SONOFF Devices

Supports Devices Controlled Via LAN

2. "Matter Bridge" Feature Supported Devices

The SONOFF Wi-Fi Device

The SONOFF Zigbee Device

The Third-Party Zigbee 3.0 Device

Home Assistant Entities

3."Thermostat" Feature Supported SONOFF Devices

The Temperature Source Device

The Thermostat Device

The Action Device

4."Smart Security" Feature Supported SONOFF Devices

The Trrigger Device

5. Compatible with Third-party Devices

Supported Third-Party Zigbee 3.0 Device Types

Supported Third-Party Matter Device Types

6. Compatible with Home Assistant

Device Types in HA That Can be Synced to NSPanel Pro

Device Types in NSPanel Pro That Can be Synced to HA

Reading next

Subscribe now ＆ get 10% off your first order

Select Your Country/Region

Americas

Europe

Other
